5 layer plastic blowing machinery

Usage: Plastic blowing machinery (5 layer co-extrusion nylonblown film machine)is mainly used for blowing with material of LDPE, LLDPE, MLLDPE,PA,EVA, EVOH to produce symmetrical and unsymmetrical barrier film with high quality properties such as boiling, preservation, high sealing, high mechanical trength, high transparency and high barrier performance. The film are widely used in food packaging, liquid packaging, pharmaceutical packaging, medical equipment, chemical products, daily necessities, etc. Features: 1)High quality mixing screw 2)Grooved feeding barrel 3)Multi-layer(5-layer) co-extrusion pan stackable die head 4)IBC(Internal Bubble Cooling) system 5)360°horizontal reversing haul-off system 6)Dual-lip high efficiency air ring 7)Full auto winding system with computer PLC control 8)Full auto winding system with auto tenstion control 9)Dual photoelectric utomatic EPC control system 10)Centralized computer control system Detail Technical Parameters: Model SJ-5C-BL1200SJ-5C-BL1400SJ-5C-BL1600Co-extrusion Layers 5 Layers5 Layers5 LayersSuitable Material PA, EVA, EVOH, LDPE, LLDPE, mLLDPEMax. Folding Film Width 1100mm1300mm1500mmFilm Thickness 0.035-0.20mm0.035-0.20mm0.035-0.20mmMax. Output 120kg/hr150hr/hr200kg/hrScrew Diameter Ø40/ Ø40/ Ø45/ Ø40/ Ø40Ø45/ Ø45/ Ø50/ Ø45/ Ø45Ø45/ Ø50/ Ø55/ Ø50/ Ø45Screw Ratio(L/D) 28:1, 30:128:1, 30:128:1, 30:1Max. Screw Speed 120r/minMain Extruder Motor 15/15/18.5/15/15KW18.5/18.5/22/18.5/18.5KW18.5/22/37/22/18.5KWMode of Bubble Cooling Dual Lip Air RingIBC (Internal Bubble Cooling)Dual Lip Air RingIBC (Internal Bubble Cooling)Dual Lip Air RingIBC (Internal Bubble Cooling)Mode of Reversing 360º Horizontal Reversing Haul-Off360º Horizontal Reversing Haul-Off360º Horizontal Reversing Haul-OffWidth of Auxiliary Machine 1200mm1400mm1600mmWinding Mode Full Automatic WindingMax. Winding Diameter Ø600Machine Dimension (LxWxH) 10000x5200x7800mm10300x6500x8500mm10500x7000x9200mmWeight of the Machine Approx. 26000KGApprox. 35000KGApprox. 40000KGContinuous Gravimetric Measure System OptionalAutomatic Air Ring & Web Guiding System Optional
